Endoscopic obliterative therapy with n-butyl-2-cyanoacrylate for gastrointestinal varices

Takahiro Sato

Department of Gastroenterology, Sapporo Kosei General Hospital, Sapporo, Japan

E-mail : taka.sato@ja-hokkaidoukouseiren.or.jp

DOI: 10.15761/GHE.1000126

Article
Article Info
Author Info
Figures & Data

Abstract

Aims: To evaluate the utility of endoscopic obliterative therapy with n-butyl-2-cyanoacrylate (tissue adhesives) for gastrointestinal varices and to investigate the incidence of serious complications.

Methods: Endoscopic obliterative therapy with n-butyl-2-cyanoacrylate was performed on 228 gastrointestinal variceal patients; 221 gastric varices, 5 duodenal varices, and 2 anastomotic varices after choledochojejunostomy. Endoscopic therapy was performed under fluoroscopy using 70% or 83% cyanoacrylate diluted with 5% Lipiodol.

Results: Endoscopic obliterative therapy with cyanoacrylate for gastrointestinal varices was successful in all 228 cases. The incidence of serious complications was 4/228 (1.8%), including two cases of splenic infarction, one of pulmonary embolism, and one of an inflammatory tumor of the pancreatic tail, and all these 4 cases for gastric varices.

Conclusions: Endoscopic obliterative therapy with cyanoacrylate is a useful and relatively safe method for treatment of bleeding gastrointestinal varices. Nonetheless, careful attention must be paid to avoid potentially serious complications.

Keywords

N-butyl-2-cyanoacrylate, endoscopic obliterative therapy, gastrointestinal varices, Histoacryl®

Introduction

Gastrointestinal variceal hemorrhage is a common complication with portal hypertension and is associated with higher morbidity and mortality rates than in patients with esophageal variceal bleeding. Gastric varices (GV) classified as gastroesophageal varices type 2 (GOV2) or isolated gastric varices 1 (IGV1) with Sarin classification [1] are more severe and often difficult to treat as compared to the other types of varices. Bleeding GV of these types can be treated successfully by injection of cyanoacrylate. N-butyl-2-cyanoacrylate (Histoacryl®, B.Braun Dexon GmbH Spangenberg, Germany) is a tissue glue monomer that polymerizes and solidifies instantly upon contact with blood. Soehendra et al. were the first to report the usefulness of n-butyl-2-cyanoacrylate in the treatment of bleeding GV [2].

 On the other hand, ectopic varices are defined as portosystemic venous collaterals occurring anywhere in the gastrointestinal tract other than the esophagogastric region. Duodenal varices (DV) are considered ectopic varices, and account for 1-3% of all varices in patients with portal hypertension [3,4]. DV are reported to be the second most common cause of ectopic variceal bleeding after the rectal varices [5]. Bleeding from DV is generally massive, and diagnosis of ruptured duodenal varices along with the control of hemorrhage is difficult. Anastomotic varices after choledochojejunostomy are an uncommon cause of variceal bleeding, and it should be considered when evaluating gastrointestinal hemorrhage in patients with previous surgery and mesenteric venous hypertension.

Anastomotic varices after choledochojejunostomy drain directly into the intrahepatic portal vein. Therefore, endoscopic treatment is difficult for this condition and endoscopic obliterative therapy with n-butyl-2-cyanoacrylate is the preferred treatment.

The aim of the present study was to evaluate the utility of endoscopic obliterative therapy with n-butyl-2-cyanoacrylate for gastrointestinal varices and to investigate the incidence of serious complications.

Methods

Patients

Two hundred twenty-eight patients with gastrointestinal varices and portal hypertension who underwent endoscopic obliteration therapy with n-butyl-2-cyanoacrylate were evaluated retrospectively (147 men and 81 women; age range, 30-81 years; mean, 62.5 years). Among these patients, 74 were emergency cases and the other 154 were prophylactic cases. The pathology underlying portal hypertension was liver cirrhosis (LC) in 206 patients, splenic vein occlusion (left-sided portal hypertension) in 9, extrahepatic portal obstruction in 8 (including 2 patients after choledochojejunostomy), and idiopathic portal hypertension in the remaining five. LC was confirmed by a combination of clinical, biochemical, and ultrasound criteria. Etiologies of cirrhosis in the 206 cases included 31 with hepatitis B surface antigen (HBs Ag) - positivity, 88 with hepatitis C virus (HCV) - positivity, 60 with alcoholic liver disease, 5 with primary biliary cirrhosis, one of autoimmune hepatitis, and 21 with unknown etiology.

The study was performed according to the Declaration of Helsinki, and was approved by the Ethics Committee at Sapporo Kosei Hospital. Written informed consent was obtained from all patients prior to the procedure.

Endoscopic findings

GV; according to the Sarin classification1, IGV1 were present in 104 patients, GOV2 in 108, and ectopic varices seen outside the fundus (IGV2) in nine. DV; location of DV was the second portion of duodenum in 4 cases and duodenal bulb in 1. Anastomotic varices after choledochojejunostomy; endoscopy revealed large, coil-shaped varices in the afferent jejunal loop in 2 cases.

Methods

In 74 emergency cases, endoscopic examination was performed after stabilizing the general condition of the patients. When bleeding was spurting or oozing, a red or white plug, or tiny erosion was observed at the gastrointestinal varices during emergency endoscopic examination (Figure 1), endoscopic obliteration using n-butyl-2-cyanoacrylate for hemostasis was performed immediately. Prophylactic endoscopic obliteration therapy using n-butyl-2-cyanoacrylate was performed on the remaining 154 patients due to the high risk of bleeding, which was determined by the presence of varices that enlarged in a short time, showed red color sign or erosion on their surface. Terlipressin was not routinely used before procedures.

Figure 1. Spurting gastric variceal bleeding during emergency endoscopic examination.

For endoscopic obliterative therapy for gastrointestinal varices, we used n-butyl-2-cyanoacrylate diluted to a final concentration of 70% or 83% (except one case of duodenal varices) in 5% Lipiodol®, (Guerbet Asia Pacific, Tsuen Wan, Hong Kong). Lipiodol® prevents the tissue adhesive from polymerizing too quickly and also allows for radiographic monitoring. Obliterative therapy was performed repeatedly every week with a 23-gauge needle until gastrointestinal varices disappeared. Fluoroscopic observation with an infusion of n-butyl-2-cyanoacrylate (avoiding flow into the systemic circulation) was performed to determine the extent of the varices (Figure 2a and 2b).

Figure 2-a. Endoscopic obliterative therapy using 70% n-butyl-2-cyanoacrylate for gastric varices

Figure 2-b. Fluoroscopic image of endoscopic obliterative therapy

We evaluated the utility of endoscopic obliterative therapy with n-butyl-2-cyanoacrylate for gastrointestinal varices and assessed the incidence of serious complications.

Results

Endoscopic obliterative therapy with cyanoacrylate for gastrointestinal varices was successful in all 228 cases. The incidence of serious complications was 4/228 (1.8%), including two cases of splenic infarction, one case of pulmonary embolism, and one of an inflammatory tumor of the pancreatic tail, and all these 4 for GV.

1. Gastric varices (GV, n=221)

Eighteen of 68 emergency cases showed active bleeding from GV, whereas a fibrin plug or erosion of the variceal surface was detected in the other 50 patients. Endoscopic hemostasis was successful in all 68 cases. Among these 221 patients including prophylactic cases, the number of endoscopic treatments required for variceal eradication varied from 1 to 6. Total amount of n-butyl-2-cyanoacrylate used ranged from 1.5-8.0 ml with a mean of 2.6 ml. For endoscopic obliterative therapy for GV, we used n-butyl-2-cyanoacrylate diluted to a final concentration of 70% in all cases. The incidence of serious complications was 4/221 (1.8%), including two cases of splenic infarction, one of pulmonary embolism, and one of an inflammatory tumor of the pancreatic tail. The two patients with splenic infarction improved under a conservative medical treatment. The patient with pulmonary embolism showed no respiratory symptoms, and died of liver failure. The patient with the pancreatic tumor, which was diagnosed as an inflammatory tumor, was treated surgically.

2. Duodenal varices (DV, n=5)

Two of 4 emergency cases showed active bleeding from DV, whereas a fibrin plug or erosion of the variceal surface was detected in the other 2 patients. Endoscopic hemostasis was successful in all 4 in emergency cases. Among these 5 patients including prophylactic case, the number of endoscopic treatments required for variceal eradication varied from 1 to 2. Total amount of n-butyl-2-cyanoacrylate used ranged from 0.5-1.0 ml with a mean of 0.7 ml. For endoscopic obliterative therapy for DV, we used n-butyl-2-cyanoacrylate diluted to a final concentration of 70% in 4 cases, and n-butyl-2-cyanoacrylate without contrast medium in 1 case of extrahepatic portal vein obstruction. The incidence of serious complications was 0/5 (0%) in DV. In 2 of 5 patients, balloon-occluded retrograde transvenous obliteration (B-RTO) was performed for remaining duodenal varices as an additional treatment.

3. Anastomotic varices after choledochojejunostomy (n=2)

One of 2 emergency cases showed active bleeding from anastomotic varices, whereas a fibrin plug or erosion of the variceal surface was detected in the other patient. Endoscopic hemostasis was successful in all 2. Among these patients, the number of endoscopic treatments required for variceal eradication varied from 1 to 2. Total amount of n-butyl-2-cyanoacrylate used ranged from 0.5-1.5 ml with a mean of 1.0 ml. For endoscopic obliterative therapy for anastomotic varices, we used n-butyl-2-cyanoacrylate diluted to a final concentration of 83%. The incidence of serious complications was 0/2 (0%).

Discussion

N-butyl-2-cyanoacrylate polymerizes immediately on contact with blood, resulting in rapid hemostasis, and endoscopic treatment using this material is the first-choice endoscopic treatment worldwide for obliteration of bleeding GV [2, 6-11]. GV hemorrhage is associated with higher morbidity and mortality rates than those with esophageal variceal bleeding.  Cardiofundal GV classified as GOV2 or IGV1 on the Sarin endoscopic classification1 are more severe and often difficult to treat as compared to the other types of varices, and endoscopic obliterative therapy with cyanoacrylate is a good indication for these types of GV.

Currently, therapeutic strategies for GV bleeding include transjugular intrahepatic portosystemic shunt (TIPS) [12,13], cyanoacrylate endoscopic obliterative therapy and B-RTO, but the optimal management of bleeding GV remains controversial due to the lack of randomized, controlled trials. Large GV tend to bleed at lower pressures compared with esophageal varices [11], and TIPS seems to be less effective for treating GV bleeding than for esophageal variceal bleeding [14]. TIPS have been associated with problems in some patients, including complications such as encephalopathy and occlusion of the TIPS route [15,16]. Cost-effective analyses comparing cyanoacrylate injection therapy with TIPS have suggested that cyanoacrylate injection therapy is safe and effective for GV bleeding, in addition to being relatively lower in cost [17,18].

The B-RTO has been reported successfully for GV management, primarily in Japan [19]. As an elective use, however, it is unsuitable for acute GV bleeding. This procedure is very useful for the prevention of GV re-bleeding after endoscopic therapy. However, this procedure induces an increase of portal pressure because of the obliteration of a large portosystemic shunt and results in significant aggravation of several associated problems, including ascites, hepatic hydrothorax, intestinal wall edema, and esophageal varices [20,21].

Endoscopic obliterative therapy with n-butyl-2-cyanoacrylate is useful for emergency control of acute gastric variceal bleeding of GOV2 or IGV1 types. Recent articles conclude that endoscopic obliterative therapy with n-butyl-2-cyanoacrylate is a highly effective modality for immediate hemostasis of gastric variceal bleeding and is associated with an acceptable re-bleeding rate [22]. Kumar et al reported that undiluted n-butyl-2-cyanoacrylate was effective in achieving initial hemostasis in case of actively bleeding gastric varices, and was very safe and not associated with embolic complications [22]. However, in many Japanese institutions, n-butyl-2-cyanoacrylate is mixed with a contrast medium, radiopaque Lipiodol®, to allow radiologic monitoring during and after injection. To prevent n-butyl-2-cyanoacrylate from solidifying too quickly, dilution with Lipiodol is necessary.

Hemorrhage from DV is often a serious condition [3], with mortality as high as 40% at initial bleeding [23,24]. Varices in the duodenal bulb, which most frequently occur in the United States and Europe, are caused by extrahepatic portal obstruction (EHO). Several articles were reported about DV bleeding caused by EHO [25-27]. In Japan, duodenal varices are observed more commonly in the second portion of the duodenum [28]. Interventional radiologic techniques such as TIPS, B-RTO, are options for hemorrhaging duodenal varices and successful treatments have been reported, including TIPS [24] and B-RTO [29-31]. Endoscopic treatments have been performed successfully for duodenal varices.

Endoscopic variceal ligation (EVL) is useful for obtaining hemostasis [28], however, re-bleeding of varices is a weak point with EVL. Additional treatment is recommended after EVL for duodenal varices.

EIS has been performed successfully for the treatment of duodenal variceal bleeding [32], but there were serious problem of re-bleeding of the varices [24,33]. Endoscopic therapy using n-butyl-2-cyanoacrylate is also very useful for massive duodenal variceal bleeding [27,34,35] because of the high blood velocity and blood flow. Hemorrhaging from varices in the jejunal loop, with extrahepatic portal vein obstruction after choledochojejunostomy, is a rare condition but several articles have been published [36-38].

Various medical treatments, such as interventional radiology and surgery, have been used to control bleeding from anastomotic varices after choledochojejunostomy; however, there is no best treatment strategy for anastomotic varices. [36,37,39,40] Endoscopic treatment is difficult for this condition and endoscopic obliterative therapy with n-butyl-2-cyanoacrylate is the preferred treatment for this type of varix [41,42].

Serious complications of n-butyl-2-cyanoacrylate, including embolization to the brain [43], portal vein [44], lung [45-50], and spleen [50,51] have also been reported. In this research, complications related to the procedure occurred in 4 patients, including 2 cases of splenic infarction, 1 case of pulmonary embolism, and 1 case of inflammatory tumor of the pancreatic tail, and all 4 cases were evaluated in the gastric variceal group. Risk factors for extravariceal embolization associated with n-butyl-2-cyanoacrylate treatment include a large injection volume, dilution of radiolucent n-butyl-2-cyanoacrylate with radiopaque Lipiodol®, speed of injection, and the presence of shunts.  The two main risk factors for extravariceal embolization with n-butyl-2-cyanoacrylate treatment include large injection volume and dilution of radiolucent n-butyl-2-cyanoacrylate with radiopaque Lipiodol®. Larger volumes of n-butyl-2-cyanoacrylate used for treating varices of higher blood volumes increase the chance of leakage, and by prolonging polymerization, overdilution with Lipiodol® can increase the risk of embolizaion. To avoid embolic complications as much as possible, we recommend that endoscopists aim to use the smallest volume of n-butyl-2-cyanoacrylate necessary for obliteration, and to use n-butyl-2-cyanoacrylate in the most concentrated form practicable.

Endoscopic obliterative therapy with a low concentration of n-butyl-2-cyanoacrylate has the potential to cause intrahepatic obstruction of the portal vein in the patients with anastomotic varices after choledochojejunostomy. Therefore, we carried out endoscopic obliterative therapy in these patients with a high concentration of n-butyl-2-cyanoacrylate.

Conclusion

In conclusions, our results demonstrated the high efficacy and relative safety of n-butyl-2-cyanoacrylate used in treating gastrointestinal varices. However, careful attention must be paid to avoid potentially serious complications.

Appendix

References

  1. Sarin SK, Lahoti D, Saxena SP, Murthy NS, Makwana UK (1992) Prevalence, classification and natural history of gastric varices: a long-term follow-up study in 568 portal hypertensive patients. Hepatology 16: 1343-1349. [Crossref]
  2. Soehendra N, Nam VC, Grimm H, Kempeneers I (1986) Endoscopic obliteration of large esophagogastric varices with bucrylate. Endoscopy 18: 25-26. [Crossref]
  3. D,Imperio, Piemontese A, Baroncini D, Billi P, Borioni D, et al. (1996) Evaluation of undiluted N-butyl 2- cyanoacrylate in endoscopic treatment of upper gastrointestinal tract varices. Endoscopy 28: 239-243. [Crossref]
  4. Norton ID, Andrews JC, Kamath PS (1998) Management of ectopic varices. Hepatology 28: 1154-1158. [Crossref]
  5. Watanabe N, Toyonaga A, Kojima S, Takashimizu S, Oho K, et al. (2010) Current status of ectopic varices in Japan: Results of a survey by the Japan Society for Portal Hypertension. Hepatol Res 40: 763-776. [Crossref]
  6. Ogawa K, Ishikawa S, Naritaka Y, Shimakawa T, Wagatsuma Y, et al. (1999) Clinical evaluation of endoscopic injection sclerotherapy using n-butyl-2-cyanoacrylate for gastric variceal bleeding. J Gastroenterol Hepatol 14: 245-250. [Crossref]
  7. Huang YH, Yeh HZ, Chen GH, Chang CS, Wu CY, et al. (2000) Endoscopic treatment of bleeding gastric varices by N-butyl-2-cyanoacrylate (Histoacryl) injection: long-term efficacy and safety. Gastrointest Endosc 52: 160-167. [Crossref]
  8. Dhiman RK, Chawla Y, Taneja S, Biswas R, Sharma TR, et al. (2002) Endoscopic sclerotherapy of gastric variceal bleeding with N-butyl-2-cyanoacrylate. J Clin Gastroenterol 35: 222-227. [Crossref]
  9. Akahoshi T, Hashizume M, Shimabukuro R, Tanoue K, Tomikawa M, et al. (2002) Long-term results of endoscopic Histoacryl injection sclerotherapy for gastric variceal bleeding: a 10-year experience. Surgery 131: S176-181. [Crossref]
  10. Fry LC, Neumann H, Olano C, Malfertheiner P, Mönkemüller K (2008) Efficacy, complications and clinical outcomes of endoscopic sclerotherapy with N-butyl-2-cyanoacrylate for bleeding gastric varices. Dig Dis 26: 300-303. [Crossref]
  11. Sato T, Yamazaki K (2010) Evaluation of therapeutic effects and serious complications following endoscopic obliterative therapy with Histoacryl. Clin Exp Gastroenterol 3: 91-95. [Crossref]
  12. Tripathi D, Therapondos G, Jackson E, Redhead DN, Hayes PC (2002) The role of the transjugular intrahepatic portosystemic stent shunt (TIPSS) in the management of bleeding gastric varices: clinical and haemodynamic correlations. Gut 51: 270-274. [Crossref]
  13. Azoulay D, Castaing D, Majno P, Saliba F, Ichaï P, et al. (2001) Salvage transjugular intrahepatic portosystemic shunt for uncontrolled variceal bleeding in patients with decompensated cirrhosis. J Hepatol 35: 590-597. [Crossref]
  14. 2021 Copyright OAT. All rights reserv
  15. Chau TN, Patch D, Chan YW, Nagral A, Dick R, et al. (1998) "Salvage" transjugular intrahepatic portosystemic shunts: gastric fundal compared with esophageal variceal bleeding. Gastroenterology. 114: 981-987. [Crossref]
  16. Ryan BM, Stockbrugger RW, Ryan JM (2004) A pathophysiologic, gastroenterologic, and radiologic approach to the management of gastric varices. Gastroenterology 126: 1175-1189. [Crossref]
  17. Tripathi D, Ferguson JW, Therapondos G, Plevris JN, Hayes PC (2006) Review article: recent advances in the management of bleeding gastric varices. Aliment Pharmacol Ther 24: 1-17. [Crossref]
  18. Mahadeva S, Bellamy M.C, Kessel D, Davies MH, Millson CE (2003) Cost-effectiveness of N-butyl-2-cyanoacrylate (histoacryl) glue injections versus transjugular intrahepatic portosystemic shunt in the management of acute gastric variceal bleeding. Am J Gastroenterol 98: 2688-2693. [Crossref]
  19. Lo GH, Liang HL, Chen WC, Chen MH, Lai KH, et al. (2007) A prospective, randomized controlled trial of transjugular intrahepatic portosystemic shunt versus cyanoacrylate injection in the prevention of acute gastric variceal bleeding. Endoscopy 39: 679-685. [Crossref]
  20. Kanagawa H, Mima S, Kouyama H, Gotoh K, Uchida T, et al. (1996) Treatment of gastric fundal varices by balloon-occluded retrograde transvenous obliteration. J Gastroenterol Hepatol 11: 51-58. [Crossref]
  21. Cho SK, Shin SW, Yoo EY, Do YS, Park KB, et al. (2007) The short-term effects of balloon-occluded retrograde transvenous obliteration, for treating gastric variceal bleeding, on portal hypertensive changes: a CT evaluation. Korean J Radiol 8: 520-530. [Crossref]
  22. Tanihara H, Minamiguchi H, Sato M, Kawai N, Sonomura T, et al. (2009) Change in portal systemic pressure gradient after balloon-occluded retrograde transvenous obliteration of gastric varices and aggravation of esophageal varices. Cardiovasc Intervent Radiol 32: 1209-1216. [Crossref]
  23. Kumar A, Singh S, Madan K, Garg PK, Acharya SK (2010) Undiluted N-butyl cyanoacrylate is safe and effective for gastric variceal bleeding. Gastrointest Endosc 72: 721-727. [Crossref]
  24. Khouqeer F, Morrow C, Jordan P (1987) Duodenal varices as a cause of massive upper gastrointestinal bleeding. Surgery 102: 548-552. [Crossref]
  25. Jonnalagadda SS, Quiason S, Smith OJ (1998) Successful therapy of bleeding duodenal varices by TIPS after failure of sclerotherapy. Am J Gastroenterol 93: 272-274. [Crossref]
  26. Bosch A, Marsano L, Varilek GW (2003) Successful obliteration of duodenal varices after endoscopic ligation. Dig Dis Sci 48: 1809-1812. [Crossref]
  27. Gunnerson AC, Diehl DL, Nguyen VN, Shellenberger MJ, Blansfield J (2012) Endoscopic duodenal variceal ligation: a series of 4 cases and review of the literature. Gastrointest Endosc 76: 900-904. [Crossref]
  28. Kao WY, Wu WC, Chen PH, Chiou YY (2012) Duodenal variceal bleeding caused by chronic pancreatitis. Gastrointest Endosc 75: 922-923. [Crossref]
  29. Shiraishi M, Hiroyasu S, Higa T, Oshiro S, Muto Y (1999) Successful management of ruptured duodenal varices by means of endoscopic variceal ligation: report of a case. Gastrointest Endosc 49: 255-257. [Crossref]
  30. Ohta M, Yasumori K, Saku M, Saitsu H, Muranaka T, et al. (1999) Successful treatment of bleeding duodenal varices by balloon-occluded retrograde transvenous obliteration: a transjugular approach. Surgery 126: 581-583.
  31. Akazawa Y, Murata I, Yamao T, Yamakawa M, Kawano Y, et al.  (2003) Successful management of bleeding duodenal varices by endoscopic variceal ligation and balloon-occluded retrograde transvenous obliteration. Gastrointest Endosc 58: 794-797. [Crossref]
  32. Sonomura T, Horihara K, Yamahara K, Dozaiku T, Toyonaga T, et al. (2003) Ruptured duodenal varices successfully treated with balloon-occluded retrograde transvenous obliteration: usefulness of microcatheters. Am J Radiol 181: 725-727. [Crossref]
  33. Barbish AW, Ehrinpreis MN (1993) Successful endoscopic injection sclerotherapy of a bleeding duodenal varix. Am J Gastroenterol 88: 90-92. [Crossref]
  34. Hashiguchi M, Tsuji H, Shimono J, Azuma K, Fujishima M (1999) Ruptured duodenal varices: an autopsy case report. Hepatogastroenterology 46: 1751-1754. [Crossref]
  35. Yoshida Y, Imai Y, Nishikawa M, Nakatukasa M, Kurokawa M, et al. (1997) Successful endoscopic injection sclerotherapy with N-butyl-2-cyanoacrylate following the recurrence of bleeding soon after endoscopic ligation for ruptured duodenal varices. Am J Gastroenterol 92: 1227-1229. [Crossref]
  36. Kim HH, Kim SE (2012) Ruptured Duodenal Varices Successfully Managed by Endoscopic N-butyl-2-cyanoacrylate Injection. J Clin Med Res 4: 351-353. [Crossref]
  37. Hiraoka K, Kondo S, Ambo Y, Hirano S, Omi M, et al. (2001) Portal venous dilatation and stenting for bleeding jejunal varices: report of two cases. Surg Today 31: 1008-1011. [Crossref]
  38. Ota S, Suzuki S, Mitsuoka H, Unno N, Inagawa S, et al. (2005) Effects of a portal venous stent for gastrointestinal hemorrhage from jejunal varices caused by portal hypertension after pancreatoduodenectomy. J Hepatobiliary Pancreat Surg 12: 88-92. [Crossref]
  39. Kitagawa S, Sato T, Kimura M (2015) Endoscopic sclerotherapy with a high concentration of n-butyl-2-cyanoacrylate for anastomotic varices after choledochojejunostomy. Endoscopy 47: E321-E322. [Crossref]
  40. Stafford Johnson DB, Narasimhan D (1997) Case report: successful treatment of bleeding jejunal varices using mesoportal recanalization and stent placement: report a case and review of the literature. Clin Radiol 52: 562-565. [Crossref]
  41. Taniguchi H, Moriguchi M, Amaike H, Fuji N, Murayama Y, et al. (2008) Hemorrhage from varices in hepaticojejunostomy in the fifth and tenth year after surgery for hepatic hilar bile duct cancer: a case report. Cases J 1: 59. [Crossref]
  42. Bhasin DK, Sharma BC, Sriram PV, Makharia G, Singh K (1999) Endoscopic management of bleeding ectopic varices with histoacryl. HPB Surg 11: 171-173. [Crossref]
  43. Gubler C, Glenck M, Pfammatter T, Bauerfeind P (2012) Successful treatment of anastomotic jejunal varices with N-butyl-2-cyanoacrylate (Histoacryl): single-center experience. Endoscopy 44: 776-779. [Crossref]
  44. See A, Florent C, Lamy P, Lévy VG, Bouvry M (1986) [Cerebrovascular accidents after endoscopic obturation of esophageal varices with isobutyl-2-cyanoacrylate in 2 patients]. Gastroenterol Clin Biol. 10: 604-607. [Crossref]
  45. Mostafa I, Omar MM, Nouh A (1997) Endoscopic control of gastric variceal bleeding with butyl cyanoacrylate in patients with schistosomiasis. J Egypt Soc Parasitol 27: 405-410. [Crossref]
  46. Thakeb F, Salama Z, Salama H, Abdel Raouf T, Abdel Kader S, et al. (1995) The value of combined use of N-butyl-2-cyanoacrylate and ethanolamine oleate in the management of bleeding esophagogastric varices. Endoscopy 27: 358-364. [Crossref]
  47. Takasugi JE, Shaw C (1989) Inadvertent bucrylate pulmonary embolization: a case report. J Thorac Imaging 4: 71-73. [Crossref]
  48. Mostafa I, Omar MM, Nouh A (1997) Endoscopic control of gastric variceal bleeding with butyl cyanoacrylate in patients with schistosomiasis. J Egypt Soc Parasitol 27: 405-410. [Crossref]
  49. Roesch W, Rexroth G (1998) Pulmonary, cerebral and coronary emboli during bucrylate injection of bleeding fundic varices. Endoscopy 30: S89-90. [Crossref]
  50. Hwang SS, Kim HH, Park SH, Kim SE, Jung JI, et al. (2001) N-butyl-2-cyanoacrylate pulmonary embolism after endoscopic injection sclerotherapy for gastric variceal bleeding. J Comput Assist Tomogr 25: 16-22. [Crossref]
  51. Tan YM, Goh KL, Kamarulzaman A, Tan PS, Ranjeev P, et al. (2002) Multiple systemic embolisms with septicemia after gastric variceal obliteration with cyanoacrylate. Gastrointest Endosc 55: 276-280. [Crossref]
  52. Cheng PN, Sheu BS, Chen CY, Chang TT, Lin XZ (1998) Splenic infarction after histoacryl injection for bleeding gastric varices. Gastrointest Endosc 48: 426-427. [Crossref]
